Poe Full Gigabit Optical Fiber Switch 1 - Optical 5 - Electric

Name: Poe Full Gigabit Optical Fiber Switch 1 - Optical 5 - Electric
Brand: HK
SKU: HK-PG-F1R5
Price: 17.8 USD
Availability: InStock
Rating: 4.8 (156 reviews)

Minimum Order Quantity :	100PCS	Price :	USD17.8
Packaging Details :	1189528mm	Delivery Time :	10-15WORKING DAYS
Payment Terms :	L/C, D/A, D/P, Western Union	Supply Ability :	5000pcs/Week

Place of Origin:	Shenzhen	Brand Name:	HK
Certification:	CCC, CE, FCC, RoHS	Model Number:	HK-PG-F1R5

Detail Information
Function:	POE	Dimension:	195×135×38mm
Weight:	0.65kg	Ports:	6*100M Ethernet Port, 4 Ports Have POE Function
Input Voltage::	AC100V～240V 50/60Hz	Data Rate:	10/100M Adaptive
Distance:	250m

Product Description

Full Gigabit 1-optical 5-electric Poe optical fiber switch

Overview

HK-PG-F1R5 Gigabit Poe switch provides 4 Gigabit Poe ports and 1 Gigabit electrical port +1 Gigabit SFP optical port for uplink. It uses international famous brand chips. It is an economical small switch, which is widely used in small networks and monitoring systems such as homes and enterprises.
HK-PG-F1R5 Gigabit Poe switch supports ieee8023af and ieee8032at Poe standard can provide up to 30 watts of power to Poe webcam, wireless AP, Internet phone and other point receiving devices through one network cable, especially suitable for occasions where power wiring is inconvenient.
HK-PG-F1R5 Gigabit Poe switch has a unique dial switch design, providing one key isolation (VLAN) mode. In VLAN mode, ports 1~4 are isolated from each other to prevent DHCP spoofing, suppress broadcast storms, and improve network security.

Specification

project	parameter
port	4 10/100/1000base-t Poe ports 1 10/100/1000base-t uplink port 1 Gigabit SFP uplink optical port
Switching performance	Backplane bandwidth: 12g MAC address table: 4K RAM:128M Support store and forward
Standard protocol	IEEE802.3, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE 802.3ab 1000BASE-T, IEEE802. 3, IEEE802. 3i 10Base-T, IEEE802. 3u 100Base-TX/FX, IEEE 802.3ab 1000BASE-T, IEEE 802.3z 1000BASE-X, IEEE802.3x Flow Control, IEEE802.1q VLAN, IEEE 802.3z 1000BASE-X, IEEE802. 3x Flow Control, IEEE802. 1q VLAN, IEEE802.3af PoE, IEEE802.3at PoE+ IEEE802. 3af PoE, IEEE802. 3at PoE+
Transmission medium and distance	Class V line: 100M; Multimode fiber: 550m; Single mode fiber: 20/40/80/120 km
Poe	Poe port: 4 DC48V, single port MAXIMUM POWER 30W Power supply line pair: 1/2 (+), 3/6 (-)
Power Supply	Ac100~240v 50/60hz input Total power 120W
indicator light	Power indicator, VLAN mode indicator, Poe indicator, electric port link connection indicator, Electric port 1000m rate indicator, optical port link connection indicator
Use environment	Operating temperature: -10~55 ℃ Storage temperature: -40~70 ℃ Operating humidity: 10~90% non condensing Storage humidity: 5~90% non condensing
physical characteristics	Dimension (W x D x H): 200x120x44mm Weight: 0.85kg
