4EP+2E Series FTTH Router Modem 100M POE Switch 4 10 / 100Mbps POE Ports

Minimum Order Quantity :	100PCS	Price :	USD8-USD18
Packaging Details :	1189528mm	Delivery Time :	10-15WORKING DAYS
Payment Terms :	L/C, D/A, D/P, Western Union	Supply Ability :	5000000PCS/YEAR

Place of Origin:	Shenzhen	Brand Name:	HK
Certification:	CCC, CE, FCC, RoHS	Model Number:	HK-4EP+2E

Detail Information
Function:	POE	Dimension:	195×135×38mm
Weight:	0.65kg	Ports:	6*100M Ethernet Port, 4 Ports Have POE Function
Input Voltage::	AC100V～240V 50/60Hz	Data Rate:	10/100M Adaptive
Distance:	250m
Highlight:	4 Ports POE Switch 100M , FTTH Router Modem POE Switch , 4EP+2E POE Ports

Product Description

4EP+2E Series POE Switch

Overview

HK-4EP+2E is a 100M POE Switch with 4 10/100Mbps POE ports, with VLAN DIP it can easily have access to VLAN function. There are 2 10/100Mbps uplink port. Longest POE distance can reach 250M. It is designed for school, family, SEMs, small range surveillance and other network connections. All ports support wire speed forwarding and the rate is up to 100Mbps. Each port support 4KV port lightning protection to ensure stable operation.

Specification

Standards	IEEE802.3 10Base-T IEEE802.3u 100Base-TX IEEE802.3af IEEE802.1q VLAN	IEEE802.3at IEEE802.3x Flow control IEEE802.3d Spanning Tree IEEE802.3p QoS
Certifications	CCC, CE, FCC, RoHS
Ethernet Port	Connector: RJ45 Data Rate: 10/100M adaptive Distance: 250m UTP Type: UTP-5E or higher level
POE Port	Power supply: end span Battery core: 1/2+, 3/6- POE port characteristics: 15.4/30W POE total power: 65W
Performance	Processing Type: Store and Forward Transmission mode: Full /Half duplex MAC Table Size: 1K Buffer Space: 448K bit Back bandwidth: 1.2G Time Delay: ＜150μs
Power	Power Type: built-in power supply Input Voltage: AC100V～240V 50/60Hz Connector: AC Socket Power Consumption: 1.4W～3W
Environment	Storage Temperature: -40～70℃ Operating Temperature: -10～55℃ Relative Humidity: 5-95% ( no condensation)
Warranty	1 year
Physical Characteristics	Dimension: 195×135×38mm Weight: 0.65kg Color: Metal, Blue

Order information

HK-4EP+2E	6*100M Ethernet port, 4 ports have POE function

Note: 1. Default with US standard; GB, EU standards as request.
