Wireless HG8546M Huawei Echolife Modem 18W 1GE 3FE WIFI CATV GPON ONU Router
Wireless HG8546M Huawei Echolife Modem 18W 1GE 3FE WIFI CATV GPON ONU Router
Wireless HG8546M Huawei Echolife Modem 18W 1GE 3FE WIFI CATV GPON ONU Router Wireless HG8546M Huawei Echolife Modem 18W 1GE 3FE WIFI CATV GPON ONU Router Wireless HG8546M Huawei Echolife Modem 18W 1GE 3FE WIFI CATV GPON ONU Router Wireless HG8546M Huawei Echolife Modem 18W 1GE 3FE WIFI CATV GPON ONU Router
Contact Now

Wireless HG8546M Huawei Echolife Modem 18W 1GE 3FE WIFI CATV GPON ONU Router

Minimum Order Quantity : 50pcs Price : Negociatable
Packaging Details : Carton Box Delivery Time : 7-15days
Payment Terms : T/T,Western Union Supply Ability : 10000pcs/Week
Place of Origin: China Brand Name: HUAWEI
Certification: CE ROHS Anatel Model Number: HG8546M

Detail Information
PORTS: 1GE+3FE+WIFI 5DBI Wavelength: Tx 1310nm, Rx 1490nm RF1550nm
Type: Enterprise Router, FTTx Solutions Product Name: Gpon Epon ONU ONT 1ge+3fe+wifi+catv
LAN: 1*10/100/1000Mbps Adaptive Ethernet Ports,RJ45 Interface Power: ≤18W
Dimension: 185*145*50mm DC Power: 5V 1A, External AC-DC Power Adapter
RX Sensitivity: <-27dBm (1490nm) Model: 1ge+3fe+wifi+catv
High Light:

HG8546M huawei echolife modem

,

Wireless huawei echolife modem

,

18W GPON ONU router

Product Description

onu epon wifi gpon onu catv onu huawei gpon HG8546M



Characteristics

l Support flexible QinQ VLAN,DHCP server/relay and IGMP/ MLD multicast monitoring function;

l Support diagnostic monitoring and remote disabling of fiber optical;

l Support 802.11n Wi-Fi(T/R)function;

l CATV function manageable,support CATV remote shutdown;

l Support NAT and firewall function;

l WAN support networking bridge, route and bridge/route mixed mode;

l Full speed 1G non-blocking switching

l 2048 MAC address table

l Support VLAN, transparent, tag, translation, trunk, etc.

l Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc

l Integrated IEEE802.1p QoS with four level priority queues

l Support IPv4/ IPv6 IGMP snooping and MLD snooping

l Support bridge, route and bridge/route mixed mode



Technical items

Descriptions

Dimension

185*145*50mm(length*width*highs)

Net weight

≤0.3Kg

Fiber port

SC/APC (Single fiber) SC/UPC& SC/APC(Dual fiber )

Downstream rate 1.25Gbps, Upstream rate 1.25Gbps

Wavelength

Tx 1310nm, Rx 1490nm, RF1550nm

Fiber interface

SC/PC

RX sensitivity

<-27dBm (1490nm)

WLAN

IEEE802.11b/g/n,300Mbps, a built-in antenna

LAN

1*10/100/1000Mbps+3*10/100Mbp adaptive Ethernet ports, full/half duplex, RJ45 interface

Throughput

Throughput can reach 900Mbps or more

DC power

12V 1A, external AC-DC power adapter

POTS

1*FXS, RJ11 connector

Button

Reset, power, WIFI

Power

≤10W

Operation

Working temperature: -5-+55℃ working humidity:10-90%(non-condensation)

Storage

Storage temperature: -30℃-+60℃ storage humidity: 10-90%(non-condensation)

CATV

Parameters

Optical Receive

-15~+2 dBm

1.

AGC range

-8~+2 dBm

2.

Fiber return loss

>50 dB

3.

wave length

1100~1600 nm

4.

Connector

SC/APC

5.

C/N

≥ 50 dB

6.

C/CTB

≥ 62 dB

7.

C/CSO

≥ 61 dB

8.

BW

40~ 1000 MHz

9.

Output level

≥ 82 dBμV


Products Description
GPON ONT HG8546M optical network terminal (ONT) is a indoor optical network terminal in FTTx solution. By using GPON technology, ultra-broadband access is provided for home and SOHO users. The HG8546M provides three FE Ethernet ports, one GE Ethernet port, one POTS port and one USB. HG8546M has WiFi function, support 802.11 b/g/n.
