V2802DAC WIFI5 ONU 2GE GPON ONT AC WIFI 2.4G 5G WIFI XPON ONU

Name: V2802DAC WIFI5 ONU 2GE GPON ONT AC WIFI 2.4G 5G WIFI XPON ONU
Brand: VSOL
SKU: V2802DAC
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (154 reviews)

Minimum Order Quantity :	10pcs	Price :	Negociatable
Packaging Details :	carton box	Delivery Time :	10-15 days
Payment Terms :	L/C, T/T	Supply Ability :	20000pcs/Week

Place of Origin:	GUANGDONG	Brand Name:	VSOL
Certification:	CE ROHS Anatel	Model Number:	V2802DAC

Detail Information
Interface:	2GE+WiFi5	Indicators:	PWR, PON, LOS, WAN, LAN1, LAN2, 2.4G, 5G
Power Adapter:	DC 12V,1.0A	Power Supply:	≤12W

Product Description

V2802DAC WIFI5 ONU 2GE GPON ONT AC WIFI 2.4G 5G WIFI XPON ONU 0

Function Data
Management	OAM/OMCI, Telnet, WEB, TR069 Support full management of ONT functions by VSOL OLT
Internet connection	Support Bridge, Route and Bridge/Route mixed mode
Multicast	Support IGMP v1/v2/v3 Support IGMP Proxy and MLD Proxy Support IGMP Snooping and MLD Snooping
VLAN	Support VLAN tag mode Support VLAN trunk mode Support VLAN translation
Data Service Functions	Full speed non-blocking switching 2K MAC address table 8 full range VLAN ID Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc Support auto polarity detection of Ethernet ports (AUTO MDIX) Integrated IEEE802.1p QoS with four level priority queues Support IGMP v1/v2/v3 snooping/proxy and MLD v1/v2 snooping/proxy
Wireless	Support Wireless AP mode Support 802.11 b/g/n/ac Support Multiple SSID Authentication : WEP/WAP-PSK(TKIP)/WAP2-PSK(AES) Modulation type: DSSS, CCK and OFDM Encoding scheme: BPSK, QPSK, 16QAM and 64QAM, 256QAM Support EasyMesh protocol
QoS	Support 4 queues Support SP and WRR Support 802.1P and DSCP
L3	Support IPv4, IPv6 and IPv4/IPv6 dual stack Support DHCP/PPPOE/Static Support Static route Support DHCP Server Support NAT/DMZ/DDNS Support Virtual Server
Security	Support Firewall Support Mac filter Based on MAC or URL Support ACL
