Home ProductsGPON ONU ONTHG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz
HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz
HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz
Contact Now

HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz

Minimum Order Quantity : 10pcs Price : Negociatable
Packaging Details : carton box Delivery Time : 15 days
Payment Terms : L/C, T/T Supply Ability : 20000pcs/Week
Place of Origin: shenzhen Brand Name: GPON EPON ONT
Certification: CE ROHS Anatel Model Number: HG6145D

Detail Information
Warranty Time: 1year Network: WIFI
Firmware: English Power Consumption: ≤17W

Product Description

Fiberhome HG6145D FTTH is a smart gateway device for Gigabit fiber smart home solution for China Mobile. It provides 1 POTS, 4 GE/FE adaptive Ethernet ports and dual-band Wi-Fi (2.4GHz & 5GHz). Flexible, supporting plug and play, remote diagnosis, green energy saving and other features. HG6145D supports GPON and EPON technologies to achieve ultra-broadband access for home users in FTTH networking scenarios. Its high-performance forwarding capability effectively guarantees the service experience of voice, data and high-definition video, and provides ideal terminal solutions and future-oriented business support capabilities for FTTH deployment.







Feature
  • Support network storage based on FTP to provide the FTP client and server end functions. Users can download files from the FTP server in a public network to the USB interface storage device or access the USB interface storage device on the ONT via the FTP client end on the PC.
  • Support configuring protection against DoS attacks, filtering of MAC addresses, IP addresses and URL addresses, firewall and ACL rules to guarantee safe operation of the equipment.
  • Support configuring the user-defined upgrade policies through the network management system so that the equipment can be upgraded automatically after being powered on.
  • Support remote fault isolation for the ONT via the network management system. Faults can be isolated remotely according to the alarms reported to reduce the maintenance cost.

  • Specification:

    Brand Fiberhome
    Product Name HG6145D
    Type GPON
    Port type 4GE+POTS+2.4G WIFI+5G
    Firmware English
    Power DC 12V 1.5A
    Power consumption <10W
    Operating temperature -5℃ to 45℃
    Storage temperature -40℃ to 70℃
    Environmental humidity 10% to 90%,non-condensing
    Dimension 368×204×149mm
    Weight 339g approximately
    HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz 0HG6145D Dual Band GPON ONU XPON ONT FTTH 4GE 1TEL 1USB WiFi 2.4GHz 5GHz 1
