Hisilicon Chipset F601C ZTE GPON ONU 1GE EPON XPON ONT FTTH 1TEL

Place of Origin:	China	Brand Name:	HUAWEI
Certification:	CE ROHS Anatel	Model Number:	ZTE F601C

Detail Information
Type:	EPON XPON GPON	Weight:	100
Firmware:	English Firmware	Dimensions (H X W X D):	100X100X10CM
Operating Temperature:	0°C To +40°C	Operating Humidity:	5% RH To 95% RH (non-condensing)
Power Adapter Input:	100 V To 240 V AC, 50 Hz/60 Hz	System Power Supply:	11 V To 14 V DC, 1.5 A
Optical Connector:	SC/APC SC/UPC	Indicators:	Power/PON/LOS/LAN/TEL/WLAN/WPS
High Light:	SC UPC ZTE GPON ONU , ZTE GPON ONU with Hisilicon Chipset , 1TEL 1GE GPON ONU ONT

Product Description

ZTE F601 GPON 1GE ONU ONT FTTH

Item	Parameters	Specification
Interface	PON Port	1 GPON optical interface Meet 1000BASE-PX20+ standard Symmetric 1.25Gbps upstream/downstream SC single-mode fiber split ratio: 1:64 Transmission distance 20KM
	Ethernet Port(LAN)	1*GE Auto-negotiation RJ45 ports Full Duplex / Half-Duplex RJ45, Auto-MDI/MDI-X Transmission Distance 100 Meter
	Power Supply Port	12V DC input
Management	NetworkManagement	Support IEEE802.3 QAM, ONU can be remotely managed by OLT Support Remote management through SNMP and Telnet Local management
Management	Management Function	Status monitor, Configuration management, Alarm management, Log management
Environmental Specifications	Shell	Plastic casing
	Power	External 12V 0.5A AC/DC power supply adapter Power consumption: <3W
	Dimensions	78mm(L) x78mm(W) x25mm (H) 0.1kg
	Environment	Operating Temperature:0~50℃ StorageTemperature:-40~85℃ Operating Humidity:10%~90%(Non-condensing) StorageHumidity:5%~95%(Non-condensing)

Hisilicon Chipset F601C ZTE GPON ONU 1GE EPON XPON ONT FTTH 1TEL 0

Hisilicon Chipset F601C ZTE GPON ONU 1GE EPON XPON ONT FTTH 1TEL 1

Hisilicon Chipset F601C ZTE GPON ONU 1GE EPON XPON ONT FTTH 1TEL 2
