Dual Band WiFi HUAWEI GPON ONU AC1200 HUAWEI Echolife HG8245Q2 4GE 2TEL

Minimum Order Quantity :	50pcs	Price :	US $ 20-22.5
Packaging Details :	Carton Box	Delivery Time :	7-15days
Payment Terms :	T/T,Western Union	Supply Ability :	10000pcs/Week

Place of Origin:	China	Brand Name:	huawei
Certification:	CE ROHS Anatel	Model Number:	hg8245q2

Detail Information
Pon Type:	GPON EPON XPON	WiFi:	AC WiFi 2.4g 5.0g
WLAN(2.4G):	802.11 B/g/n(2.4G)	WLAN(5G):	802.11 A/n/ac(5G)
Air Interface Rate:	300Mbit/s(2.4G) 1300Mbits/s(5G)	Ports:	Dual Band Wifi + 4GE+2TEL+USB
Power Supply:	EU Power / US Power/ UK Power Optional
Highlight:	4GE 2TEL HUAWEI GPON ONU , HG8245Q2 HUAWEI GPON ONU , HUAWEI Echolife HG8245Q2

Product Description

HG8245Q2 GPON ONT dual band WiFi AC1200 GPON ONU 4GE 2TEL 2.4G 5G WiFi

The Echo Life HG8245Q2 GPON ONU, an optical network terminal (ONT), is a high-end home in FTTH solution.
By using the GPON technology, ultra-broadband access is provided for home and SOHO users. The HG8245Q2 provides 2 POTS port, 4GE Ethernet ports,1USB port and dual band wireless,2.4G/5G,featuring high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and IPTV services.

Overview

Quick Details

Model Number: HG8245Q2	Type: Gpon/ Epon , ONT ONU
Place of Origin: Guangdong, China	Brand Name: Huawei
Use: Terminal	Warranty Time: 1 year
Name: Huawei Onu HG8245Q2	Condition: Original and Brand New
Antenna: External antenna	Ports: 4GE+1Tel+2USB+2WIFI(2.4G/5G)
Optical connecto: SC/UPC, SC/APC	Color: White
Gross Weight: About 500g	MOQ: 50 SET
Single-Mode Fiber: SMF	Application: FTTH FTTB FTTX Network

Specification

Brand Name	Huawei
Place of Origin	China
Model Number	HG8245Q2 ONU
Condition	Original and Brand New
Fiber interface	SC/UPC/APC Dual mode/Singal mode
Dimension	25X19X3.5 cm
Single gross weight	0.5 kg ±
Stock Situation	Ready stock

Product Descript

XPON	GPON
Optical interface	SC/UPC
UNI	1POTS+4GE+2USB+2.4G&5G Wi-Fi
WiFi standard	2.4GHz: 2 x 2 MIMO 802.11b/g/n 5GHz: 2 x 3 MIMO 802.11a/n/ac
Antenna gain	2dBi
Dimensions(Width×Depth×Height)	265mm x 176mm x 82mm
Box Dimensions(Width×Depth×Height)	290mm x 230mm x 95mm
Box Weight(kg)	0.85kg
Power supply	Power supply: 11-14V DC, 1A
Power supply	Input power: 100-240V AC, 50/60HZ
Operating temperature and operating humidity	0ºC to 40ºC
Operating temperature and operating humidity	5% to 95%, non-condensing
Cooling	Passive cooling
Maximum number of MAC addresses learned	1024
L2 forwarding capability	200 Mbit/s downstream (with any length packets)
L2 forwarding capability	200 Mbit/s upstream (with any length packets)
IPv4 L3 forwarding capability	2Gbit/s with any length packets in downstream direction
IPv4 L3 forwarding capability	1Gbit/s with any length packets in upstream direction
IPv6 L3 forwarding capability	2Gbit/s with any length packets in downstream direction
IPv6 L3 forwarding capability	1Gbit/s with any length packets in upstream direction
Configuration method	NMS, Web, or TR069
Voice protocol	SIP, H.248
