HG8245Q2 HUAWEI GPON ONU 4GE 1VOICE 2USB 2WIFI 2.4G 5G FTTH Modem Router

Minimum Order Quantity : 50pcs Price : Negociatable
Packaging Details : Carton Box Delivery Time : 7-15days
Payment Terms : T/T,Western Union Supply Ability : 10000pcs/Week
Place of Origin: China Brand Name: GPON ONU
Certification: CE ROHS Anatel Model Number: HG8245Q2

Detail Information

Chipset: Hisilicon Firmware: English
Dimensions (H X W X D): 130x110x 35mm Weight: 0.8g
Ports: 4GE+1TEL Wi-Fi Dual Band WLAN1: 2.4GHz 2 * 2 MIMO 802.11b/g/n
WLAN2: 5.0GHz L2 Forwarding Capability: 200 Mbit/s Down/upstream
System Power Supply: 12V 1.5A Optical Connector: SC/UPC
Indicators: Power/PON/INTERNET/LAN//USB Power Supply: EU Power / US Power/ UK Power Optional
High Light:

HG8245Q2 HUAWEI GPON ONU

,

1VOICE HUAWEI GPON ONU

,

2WIFI ftth modem router

Product Description

FTTH ONT with 4GE+1VOICE+2USB+2WIFI 2.4G/5G Huawei HG8245Q2 GPON ONU
Product Description
Huawei HG8245Q2 FTTH is a routing-type ONT in the Huawei all-optical access solution. It uses GPON technology to implement ultra-broadband access for users. This model offers 4 GE+1 POTS+2 USB+2 WiFi(4 GE ports, 2 POTS ports, 1 USB port, 1 2.4G WiFi port, and 1 5G WiFi port). The high forwarding performance ensures the user experience of voice, data, and HD video services, and provides customers with an ideal all-optical access solution and future-oriented service support capability.

Smart interconnection
* Smart Wi-Fi coverage
* SIP/H.248 auto-negotiation
* Any port any service
* Parental control
* L2/L3(IPv4) forwarding: 1G uplink, 2G downlink

Smart service
* Smart Wi-Fi sharing:
Portal/802.1x authentication
SoftGRE-based sharing
* Association of one account with two POTS ports

Layer 3 Features
* PPPoE/Static IP/DHCP
* NAT/NAPT
* Port forwarding
* ALG, UPnP
* DDNS/DNS server/DNS client
* IPv6/IPv4 dual stack, and DS-Lite
* Static/Default routes
* Multiple services on one WAN port

Specification
Brand
Huawei
Model
HG8245Q2
Weight
About 1500 g
Operating temperature
0°C to +40°C
Operating humidity
5% RH to 95% RH (non-condensing)
Power adapter input
100–240 V AC, 50/60 Hz
System power supply
11–14 V DC, 2 A
Static power consumption
8 W
Maximum power consumption
20.5 W
Ports
1POTS + 4GE + 2.4G/5G Wi-Fi + 1USB
Indicators
POWER/PON/LOS/TEL/LAN/WLAN/ WPS/USB

HG8245Q2 HUAWEI GPON ONU 4GE 1VOICE 2USB 2WIFI 2.4G 5G FTTH Modem Router 0
HG8245Q2 HUAWEI GPON ONU 4GE 1VOICE 2USB 2WIFI 2.4G 5G FTTH Modem Router 1
HG8245Q2 HUAWEI GPON ONU 4GE 1VOICE 2USB 2WIFI 2.4G 5G FTTH Modem Router 2
