Cheap Price Big Style Huawei Hg8321r Gpon Epon Xpon 2fe+1tel Hgu ONU Support Ipv4/Ipv6 Firmware English Version Huawei H

Minimum Order Quantity : 100pcs Price : $7.3-$8.2
Packaging Details : Carton Box,162*141*36mm/0.2kgs Delivery Time : 15days
Payment Terms : T/T Supply Ability : 100000/week
Place of Origin: China Brand Name: HW
Certification: CE,ISO,RoHS Model Number: HG8321R

Detail Information

Color: White Pon: XPON
Condition: New Firmware: English
Specification: 1GE 1FE 1TEL Usage: FTTH

Product Description



FTTH ONT Terminal 1GE+1FE+1POTS HG8321R Router Modem Onu Gpon Wifi ONU Huawei


The HG8321R FTTH is an optical network terminal (ONT), is a high-end home Bridge in FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users.



The HG8321R: 2LAN+1POT



The EG8120L features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the EG8120L provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.



The EG8120L Provide English firmware and EU, US, UK, AU Power adapter for your choice.



Product Description



Product Description
Technical items Descriptions
Model HG8321R
Out Port contains 2FE+1TEL
WIFI signal NO
Wireless gain NO
USB NO
LAN 1*10/100Mbps adaptive Gigabit ports, full/half duplex, RJ45 interface
TEL H248/SIP Voice Protocol
PPPOE/BRIDGE Support
Firmware English
Dimension/weight 135mm*115mm*25mm/158g
Fiber port 1 GPON /EPON/XPON interface, ingle-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/UPC/APC Dual mode/Singal mode
RX sensitivity >-28dBm (1490nm)
DC power 12V 0.5A, external AC-DC power adapter
Button Reset,power
Operation Working temperature: -5- +55ºC working humidity:10-90%(non-condensation)
Storage Storage temperature: -30ºC- +60ºC storage humidity: 10-90%(non-condensation)






Features

* Rich interfaces to meet multiple application scenarios
Huawei HG8321R FTTH provides multiple interfaces including FE, GE, VoIP, E1, WiFi, RF, USB, etc., to meet the needs of
scenarios such as FTTH, FTTB, FTTO and applications for home users and business users.
* Flexible and diverse business support
It supports the development of large-bandwidth data and Internet access, VoIP, IPTV, CATV video services, and L2VPN services, and provides good QoS and security guarantees.
* Fast deployment and easy operation
Convenient installation methods and disk fibre design make installation easier. Through the batch configuration operation of the network management system, zero-configuration on-site is achieved.
* Low power consumption, green and energy saving
The corresponding status monitoring can be performed according to whether the ONT is idle or not, and enter a low power consumption state, which fully reflects the design of green energy saving and emission reduction.
* Fast fault location
It can track protocol signals and monitor ONT performance to quickly locate equipment faults.
